Bestsellers EG.D
Product code: 52461-100-eon SKU manufacturer: 8595208679780 Code of supplier: 8595208679780 Brand: ELPLAST-KPZ
€ 1 713.70
€ 1 416.28 without VAT
€ 6.10 PHE – fee for recycling

Technical specification

features:
Brand
Rated voltage 500 V
Number of phases
Mounting method Pedestal (in-ground mounting)
Rated current A
Rated current 100 A
Degree of protection (IP) IP44
Frequency 50 Hz
Impact strength IK10
Type of closure Square shaft (6 × 6 mm)
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V 10 kA
Release characteristic
Height 1785 mm
Depth 216 mm
Distribution network operator EG.D
Width 420 mm
Material Polyester, glass fibre reinforced
Number of inlets
Service connection cabinet
Connectable conductor cross section (multi-wired) mm2
Type of incoming terminal
Number of outgoing circuits
Connectable conductor cross section at the outgoing terminal mm2
Number of electricity meters
Type of outgoing terminal
Suitable for remote control of renewable energy sources (PV, small hydro, cogeneration) No
